2.2 Inch Multiple Bend Flex Sensor

Flex Bend Sensor 2.2 Inch Flex Pressure Sensor for Robot Hand Electronic Gloves Resistive Flex Sensor

Overview:

A simple flex sensor 2.2" in length. As the sensor is flexed, the resistance across the sensor increases.

Features:

• The resistance of the flex sensor changes when the metal pads are on the outside of the bend (text on inside of bend).
• Connector is 0.1" spaced and bread board friendly.
• Attention: Bending direction: the side with words is the inner side during bending. Avoid bending the end pin part (i.e. non-bending detection part) when using, otherwise it may cause damage.

Technical Specifications:

• Resistance in straight state: 25K ohms
• Resistance value tolerance: � 30%
• Bending resistance change: 60K~110K ohms
• Nominal power: 0.5 watts
• Peak power: 1 watt
• Bending life:>1 million times
• Operating temperature: -35�C~+80�C
• Length x width: 73.66�6.35mm
• Interface Type: 2-pin metal pins (0.1" spacing)

Package Includes: 1 x 2.2 inch flex sensor Version 1.0.0 Resistance in straight state: 25K ohms Resistance value tolerance: � 30% Bending resistance change: 60K~110K ohms Nominal power: 0.5 watts Peak power: 1 watt Bending life:>1 million times Operating temperature: -35�C~+80�C Length x width: 73.66�6.35mm Interface Type: 2-pin metal pins (0.1" spacing)
