DC 5V-12V to 12V Output Li-ion 18650 Battery UPS Voltage Power Supply Module

18650 Li-Ion DC UPS Voltage Converter Module – Compact and high-efficiency 5V-12V to 12V 1A constant voltage module. Ideal for uninterrupted charging, battery-powered projects, and reliable power supply for electronics, mobile devices, and IoT applications in Pakistan.

Key Features

• Supports simultaneous charging and discharging
• High current capacity for stable performance
• Compact size for easy integration in DIY projects
• High-efficiency voltage conversion
• Short circuit protection for safety

Specifications

• Product Name: UPS Voltage Converter Module
• Input Voltage: DC 5V–12V
• Output Voltage: DC 12V, 12W
• Battery Support: 3.7V Li-Ion or Li-Po battery up to 15Ah (not included)
• Operating Temperature: -40℃ to 85℃
• Operating Humidity: 0%-95% RH
• Module Size: 50 × 20 × 6.3 mm

Installation Steps

• Connect the correct input voltage to the input terminal
• Verify output voltage using a voltmeter and ammeter
• Connect the battery to B+ and B- terminals

Usage Notes

• Maximum output current is 1A; module cannot maintain 1A continuously
• Do not reverse input power polarity to avoid damage
• Optional LED indicators: Red for charging, Blue for load output
• Recommended wire thickness: >1.5 mm² for high current

Applications

• Ordinary power supply and battery charging
• Mobile power and power conversion modules
• Infrared alarm systems
• Network devices like switches and routers
• Battery-powered vehicle modifications
