GuaranteedLM2596 Buck Adjustable Step Down Power Supply Module DC-DC Converter
LM2596 DC-DC Buck Converter Step Down Module Power Supply is a step-down buck converter switching regulator. LM2596 Buck is capable of driving a 3-A load with excellent line and load regulation and fixed output voltages of 3.3 V, 5 V, 12 V, and an adjustable output version.
PKR 130/-
1
CATEGORY:Modules & Breakout Boards
Product Description
LM2596 Buck Adjustable Step Down Power Supply Module DC-DC Converter
Features of LM2596 DC-DC Buck Converter Module:
- Output ripple: 30mA maximum
- Load Regulation: ± 0.5%
- Voltage Regulation: ± 0.5%
- Dynamic Response speed: 5% 200uS
- Input voltage: 4.75-35V
- Output voltage: 1.25-26V (Adjustable)
- Output current: Rated current is 2A, maximum 3A (Additional heat sink is required)
- Conversion Efficiency: Up to 92% (output voltage higher, the higher the efficiency)
- Rectifier: Non-Synchronous Rectification
- Module Properties: Non-isolated step-down module (buck)
- Short Circuit Protection: Current limiting, since the recovery
- Operating Temperature: Industrial grade (-40 to +85) (output power 10W or less)
Pinouts of LM2596 step-down power supply module:
- Package Includes:1 x LM2596 DC-DC Buck Converter Power Supply
- Input voltage: 4-35V
- Output Voltage: 1.5-35V (adjustable)
- Output current: rated current 2A, maximum 3A (heat sink required)
- Conversion efficiency: Up to 92% (the higher the voltage, the higher the efficiency)
- Switching Frequency: 150KHz
- Rectifier: Non-Synchronous Rectification
- Module Properties: Non-isolated step-down module (buck)
- Short circuit protection: current limiting
- Operating temperature: Industrial grade (-40 ℃ to +85 ℃) (output power 10W or less)
- Full load temperature rise: 40 ℃
- Load regulation: ± 0.5%
- Voltage regulation: ± 0.5%
- Dynamic response speed: 5% 200uS
- Output ripple:Input 12V Output 5V 3A 60mV (MAX)Input 24V Output 12V 3A 120mV (MAX)
