PIC16F887 40-PIN PIC MCU Microcontroller IC

The PIC16F887 is an 8-bit microcontroller from Microchip. The 40-pin IC has 14 Channel 10-bit ADC making it suitable for applications which require more ADC inputs. The IC also has 2 Comparators, 2 Timers (8-bit and 16-bit) and supports SPI, I2C and UART communication protocols.

Features:

• High-Performance RISC CPU
• Only 35 single word instructions to learn
• All instructions are single cycle (1µs) except for program branches
• Operating speed: DC – 20MHz clock input
• 8 kBytes Flash Program Memory
• 368 Byte RAM Data Memory
• 256 Byte EEPROM Data Memory
• In-circuit Serial Programming
• Interrupt Capability (up to 10 sources)
• Two 8-bit timer/counter(TMR0, TMR2) with 8-bit programmable prescalar
• One 16 bit timer/counter (TMR1)
• High current source/sink for direct LED drive
• Watchdog Timer (WDT) with Separate RC Oscillator
• Two Capture, Compare, PWM Modules
• Synchronous Serial Port with SPI and I²C
• Fourteen Channel, 10-bit Analog to Digital Converter
• Universal Synchronous Asynchronous Receiver Transmitter (USART)
• 35 I/O pins with individual direction control
• 40-pin DIP
