XM18 Incubator Controller Thermostat Full Automatic

The XM18 Incubator Controller is a fully automatic digital thermostat designed for precise temperature and humidity control in incubators. Ideal for hatcheries and poultry enthusiasts, it ensures safe egg incubation with automatic egg turning, ventilation, and alarm systems for reliable operation.

Main Functionalities:

• Fully automatic temperature control
• Fully automatic humidity control
• Automatic egg-turning
• Automatic alarm system for safety alerts
• Automatic ventilation control
• Emergency backup system for uninterrupted operation

Technical Specifications

• Temperature display range: 0 ~ 99.9℃
• Temperature measurement accuracy: ±0.1℃
• Humidity display range: 0-99% RH
• Humidity control accuracy: ±3% RH
• Output channels: 7 paths – over-temperature, temperature control, insufficient temperature, egg-left turning, egg-right turning, humidity control, alarm
• Maximum output load: 8A/AC 220V (temperature control, insufficient temperature), 1A/AC 220V (over-temperature, egg turning, humidity, alarm)
• Egg-turning: maximum 999 times, cycle 0-999 minutes (factory default: 90 min), duration 0-999 seconds (factory default: 180 sec)
• Ventilation: cycle 0-999 minutes (factory default: 120 min), duration 0-999 seconds (factory default: 30 sec)
• Measuring line length: 1.5 meters
• Power supply: AC 160V ~ 240V, 50Hz or AC 110V
• Relative humidity: < 85%
• Ambient temperature: -10 ~ 60℃

Working Conditions

• Power supply: AC 160V ~ 240V, 50Hz or AC 110V (choose based on requirement)
• Relative humidity: < 85%
• Ambient temperature: -10 ~ 60℃
