20Kg Scale Bar Load Cell Weight Sensor

Accurately measure weight, pressure, or applied force with this high-quality straight bar load cell. Perfect for DIY projects, industrial applications, or weight monitoring systems, this sensor converts applied force up to 20kg into a precise electrical signal.

Key Features:

• Measures up to 20kg of force or pressure
• Converts strain into an electrical signal via four strain gauges in a Wheatstone bridge
• Made from durable aluminum-alloy for long-lasting performance
• IP66 rated for dust and water resistance
• Easy mounting with two M4 and two M5 through-holes
• Color-coded wiring for simple connection: Red = E+, Green = O+, Black = E-, White = O-
• Ideal for detecting weight, changes in load, or presence of objects

Product Specs:

• Sensing Range: 0 – 20 Kg
• Operating Voltage: 2.6 – 5.5V
• Operating Temperature: -40℃ to +85℃
• Dimensions: 80 x 12.6 x 12.6 mm
• Interface: Analog

Applications:

• Industrial weighing and monitoring systems
• DIY electronics and Arduino projects
• Robotics and automation sensors
• Force or pressure detection for objects and surfaces

Enhance your project or system with this precise, durable, and reliable straight bar load cell, designed to deliver consistent and accurate readings in various applications.
